Fastnet Jack 1 & 3

25m x 12.5m Combifloat Modular Jackup Barge’s
Download a full PDF vessel specsheet here

General Particullars
C5 Quadra float units – Each 12.2m X 3.05m X 1.52m
C5 Duo float units – Each 6.1m x 3.05m x 1.52m
Dimensions can be any combination of the above units as per customer spec and requirements once it forms a safe platform which meets minimum floating and elevated stability criteria.
Barge assembly layout can be altered to suit customers’ requirements. (I.e. Extra Moon pools)
Capacities
Max Deck Load: 15000Kg / M²
Max Lift: 120T / 80T Depending on barge size / spudwells in use.
Auxiliaries
Power pack 80HP Deutz Hydraulic – Twin Pump (Total of 4 Available) – Barges are normally always supplied with two power packs (i.e. One Redundant Unit)
Crane 2 Grove Hydraulic Cranes (Mounted to Combifloats Interconnectors)
1.5 TON @ 6 METRES, 8.25 TON @ 1 METRE, 370deg Slew / TELESCOPIC with 15M wire on winch.
Legs & Leg Extensions
4 x 18m Supplied as standard
4 x 8.5m bolt on extensions available as required.
Further Features
Hydraulic Winches, Warp and Delta Flipper Anchors can be supplied as required.
Loadline and Loadline exemptions included as required to meet the operational requirements of the jurisdiction.
Ideally suited to Site investigations, piling, crane work and horizontal directional drilling projects.
Vessels are fully road transportable and are supplied with full complement of required navigational and safety equipment as required.
Crew transfer boats and Tugs can be supplied on request.
